MultiWave® ECS System with 80 A Load Center, Expansion Module and Two Valve Actuators
Model#PE35065RC
Proposition 65 warning for California residents
MultiWave® ECS System with 80 A Load Center, Expansion Module and Two Valve Actuators
Model#PE35065RC
- Proposition 65 warning for California residents
- Supportingsoftware downloadsavailable
$1,784.50USD
- Eight breaker spaces
- Controls 5 circuits
- Controls 4 actuator ports (2 actuators included), 2 for pool to spa valve rotation, 1 for water feature valve rotation and 1 for solar applications
- Controls 2 heater circuits
- USB port for ease of upgrading firmware
- Load center with eight position 80 A breaker base
- Load center dead front has four knockouts for switches and GFCIs
- Remote switch for simple ON/OFF control of several components at the same time
- Heater Thermostat Control
- Motor Control
- Pump Control
CA Prop 65 Message Please see the Warning @ www.P65Warnings.ca.gov California Proposition 65 DEHP Circuit 1 Motor Display 80 LRA @120/240 VAC; 17 FLA @120/240 VAC Circuit 1 Resistive Display 20 A Circuit 2 to 5 Motor Display 60 LRA @120/240 VAC; 10 FLA @120/240 VAC Circuit 2 to 5 Resistive Display 15 A Color Beige Country of Origin (Intermatic) CHINA CSA Certification cCSAus Enclosure Type 3R Beige metal Knockout Dimensions Back (4) combination 3/4" - 1", (2) combination 3/4" - 1" Knockout Dimensions Bottom (1) 1 1/8" diameter hole, (6) combination 1/2" - 3/4", (4) 1/2", (2) combination 1 1/8" - 1 3/8" - 1 11/16" Knockout Dimensions Left (2) combination 1/2" - 3/4" Knockout Dimensions Right (1) 1 3/4" x 2 3/4" for mounting switches or GFCI Load Center Rating Display 80 A, 120/240 VAC or 120/208 VAC, Single Phase Load Center Ratings 80 A, 120 VAC, 80 A, 208 VAC, Single Phase, 80 A, 240 VAC Material Metal Motor Load Ratings Circuits 2 - 5 10 FLA @ 120 VAC, 50 Hz, 10 FLA @ 120 VAC, 60 Hz, 10 FLA @ 240 VAC, 50 Hz, 10 FLA @ 240 VAC, 60 Hz, 60 LRA @ 120 VAC, 50 Hz, 60 LRA @ 120 VAC, 60 Hz, 60 LRA @ 240 VAC, 50 Hz, 60 LRA @ 240 VAC, 60 Hz Motor Load Ratings Ranges 80 LRA @ 120/240 VAC, 50/60 Hz; 17 FLA @ 120/240 VAC, 50/60 Hz Number Of Circuits 5 Other Certifications and Compatibilities Florida Energy Efficiency Code, Title 20, Z-Wave Resistive 20 A, 120 VAC, 20 A, 240 VAC Resistive Load Ratings Circuits 2 - 5 15 A, 120 VAC, 15 A, 240 VAC RoHS Certification X Tungsten (NO) 5 A Warranty Period 2-Year limited Product Depth (in) 4.75 Product Depth (mm) 120.7 Product Height (in) 22.875 Product Height (mm) 581 Product Width (in) 14.875 Product Width (mm) 377.8 Unit Carton Height (in) 23.5 Unit Carton Length (in) 16.125 Unit Carton Weight (lb) 42.8 Unit Carton Width (in) 12.75 Units Per Pallet 18
