220-240 VAC, 50/60 Hz, 16 A, surface mounted, 1 channel intelligent twilight switch - TWS-T1CIP66-WH
Model#181900010
220-240 VAC, 50/60 Hz, 16 A, surface mounted, 1 channel intelligent twilight switch - TWS-T1CIP66-WH
Model#181900010
- Intelligent twilight mode for automatic switching with predefined hours during dusk and dawn.
- Various timer functions included (1-8 hours).
- User-friendly with our "Teach-In" mode for setting the ambient brightness level.
- Photosensitivity, 5-300 lux.
- Surface-mounted twilight switch.
- Energy savings.
- IP66 rated.
- Voltage 220-240 VAC, 50/60 Hz.
- Storage and operating temperature -20 to +45°C (-4 to +113°F).
- Billboards
- Landscape Lighting
- Outdoor Lighting Control
- Parking Lots
- Residential & Industrial Buildings
- Store Windows
- Street Lighting
Mounting Options Surface Mounting CA Prop 65 Message This product is in compliance with Prop65 California Proposition 65 None Color White Country of Origin (Intermatic) CHINA Housing Material Polycarbonate Input Voltage Range(s) 220-240 VAC Mechanism Type Electrical Operation Mode Daylight Harvesting Other Certifications and Compatibilities CB, CE, REACH RoHS Certification Y Warranty Period 2-Year limited Wiring Option Captive latching screw Operating Temperature Max (°C) 45 Operating Temperature Max (°F) 113 Operating Temperature Min (°C) -20 Operating Temperature Min (°F) -4 Product Depth (in) 1.457 Product Depth (mm) 37 Product Height (in) 4.283 Product Height (mm) 108.8 Product Width (in) 3.102 Product Width (mm) 78.8 Unit Carton Height (in) 0 Unit Carton Length (in) 0 Unit Carton Weight (lb) 0 Unit Carton Width (in) 0 Units Per Pallet 0
