Plug Module, G style plug with enhanced child protection, 13 A - PM GC
Model#162500022
Plug Module, G style plug with enhanced child protection, 13 A - PM GC
Model#162500022
- G style plug
- Modular plug design
Input Voltage Range(s) 230 VAC Input Voltage Frequencies 50 or 60 Hz Resistive Load Ratings Ranges 13 A, 250 VAC Plug Configurations Plug Type G CA Prop 65 Message This product is in compliance with Prop65 California Proposition 65 None Color Light Gray Country of Origin (Intermatic) MEXICO Cover Color Light Gray Housing Material Thermoplastics, self-extinguishing & high-temperature resistant Number of Plugs 1 Other Certifications and Compatibilities REACH, TUV RoHS Certification Y Standards and Guidelines EN 60730-1, Mode of operation and additional properties: Type 1.B Usage Environments Indoor Warranty Period 1-Year limited Operating Temperature Max (°C) 55 Operating Temperature Max (°F) 131 Operating Temperature Min (°C) -10 Operating Temperature Min (°F) 14 Product Height (in) 1.89 Product Height (mm) 48 Product Width (in) 1.61 Product Width (mm) 41 Unit Carton Height (in) 2.104 Unit Carton Length (in) 2.8 Unit Carton Weight (lb) 0.208 Unit Carton Width (in) 1.73 Units Per Pallet 4608
