- Wireless communications.
- Eliminates 3-way and multi-way wiring.
- Manual on/off and dimming operations.
- Scene selection capabilities.
- Easy to follow display.
- Selectable backlit display settings.
- Single-pole or multi-pole applications.
- Dim from multiple locations.
- Easy wiring.
- Lockable to prevent unauthorized changes.
- Supporting mobile app available on Apple app store and on Google play store
- Dimming
- Indoor Lighting Control
- Indoor Sensing Control
- Scene Control
Input Voltage Range(s) 120-277 VAC, 60 Hz Voltage Selection Type Auto Voltage 120-277 Backup Type Indefinite, Non-volatile Mount Type In-Wall Application Compatibilities ARISTA Controllers, LED Backup Protection Time Indefinite CA Prop 65 Message Please see the Warning @ www.P65Warnings.ca.gov California Proposition 65 DEHP, Lead Color White Country of Origin (Intermatic) THAILAND Data Transfer Options Bluetooth Function type Dimming, On/Off, Scene Control Material Plastic Operation Features Dimming, ON/OFF Control Other Certifications and Compatibilities Ashrae 90.1 2016, Green Energy +, IECC 2018 Programming Targets Smartphone Radio signal Bluetooth RoHS Certification X Tampering protection Yes UL Certification cULus Usage Environments Indoor Warranty Period 5-Year limited Wiring Options Line Voltage Pigtails Operating Temperature Max (°C) 55 Operating Temperature Max (°F) 131 Operating Temperature Min (°C) 0 Operating Temperature Min (°F) 32 Product Depth (in) 4.625 Product Depth (mm) 117.475 Product Height (in) 2.125 Product Height (mm) 53.975 Product Width (in) 2.875 Product Width (mm) 73.025 Unit Carton Height (in) 4.625 Unit Carton Length (in) 2.125 Unit Carton Weight (lb) 0.5 Unit Carton Width (in) 2.875 Units Per Pallet 999
